20 ft Telescopic Mast (Requires Installation Accessories)
- Brand / Vendor: SYSCOM TOWERS
- Hardware Model / MPN: SLM-6
- Deal Status: ⚡ Special Deal (20% OFF)
- Condition: 100% Brand New, Factory-Sealed Commercial Gear
- Category: Radios & Walkie Talkies
- Fulfillment Origin: Dispatches from Texas & Florida distribution hubs
- Binational Availability: Commercial procurement ready for USA and Mexico
Brand: SYSCOM TOWERS | Model / MPN: SLM-6
Availability: Immediate Dispatch from USA Warehouses
Telescopic Mast / 20 ft Extended / 10 ft Retracted / Galvanized Steel
This telescopic mast consists of two 10 ft (3 m) sections that extend to a total height of 20 ft (6 m) and retract to 10 ft (3 m) for transport and installation. Manufactured under ISO 9000 quality norms, it uses industrial-grade 20-gauge galvanized steel tubing for structural integrity in outdoor telecommunications and wireless networking deployments. The mast supports equipment loads up to 13.2 lb (6 kg) and accommodates antennas with diameters up to 9.8 in (25 cm). At 10.3 lb (4.67 kg) unit weight, it provides a compact solution for installers requiring adjustable-height mounting of wireless access points, directional panels, and parabolic antennas.
Main Features
- Two-section telescopic design: 10 ft (3 m) retracted, 20 ft (6 m) extended
- 20-gauge hot-dip galvanized industrial steel tubing
- Maximum load capacity: 13.2 lb (6 kg)
- Compatible with antennas up to 9.8 in (25 cm) diameter
- Unit weight: 10.3 lb (4.67 kg)
- Includes mounting screws
- ISO 9000 certified manufacturing
Performance Specifications
Extended height: 20 ft (6 m)
Retracted height: 10 ft (3 m)
Section length: 10 ft (3 m) each
Maximum load: 13.2 lb (6 kg)
Antenna compatibility: Up to 9.8 in (25 cm) diameter
Application: Wireless equipment, Ubiquiti and similar brands
Physical & Electrical
Tubing: 20-gauge industrial galvanized steel
Unit weight: 10.3 lb (4.67 kg)
Finish: Hot-dip galvanized
Certification: ISO 9000
Package Contents
Mast Section 2
Mast Section 3
Mounting screws
Technical Notes
- Mast use is limited to the load capacity and area specified for each mast model.
- Every mast must be secured with guy wires or at minimum good-quality galvanized wire.
- Do not climb directly on the mast or lean ladders against this telescopic mast.
- For equipment adjustment on installed mast, use A-frame ladder or scaffolding with mast retracted to minimum 10 ft (3 m) height corresponding to first section.
Typical applications: Wireless ISP installations, point-to-point and point-to-multipoint links, temporary event networks, and surveillance camera elevation.
