40 ft Telescopic Mast (Requires Installation Accessories)
- Brand / Vendor: SYSCOM TOWERS
- Hardware Model / MPN: SLM-12
- Deal Status: ⚡ Special Deal (20% OFF)
- Condition: 100% Brand New, Factory-Sealed Commercial Gear
- Category: Radios & Walkie Talkies
- Fulfillment Origin: Dispatches from Texas & Florida distribution hubs
- Binational Availability: Commercial procurement ready for USA and Mexico
Brand: SYSCOM TOWERS | Model / MPN: SLM-12
Availability: Immediate Dispatch from USA Warehouses
Telescopic Mast 40 ft (12 m) / AWG 20 Galvanized Steel / 4 Sections / Requires Installation Accessories
This telescopic mast provides a 40 ft (12 m) extended height for mounting wireless communication equipment and directional antennas. It consists of four 10 ft (3 m) sections that retract for transport and deployment. The structure is manufactured with AWG 20 industrial hot-dip galvanized steel tubing for corrosion resistance in outdoor environments. A maximum load capacity of 13.2 lbs (6 kg) and maximum antenna diameter of 9.8 in (25 cm) accommodate compact wireless radios and small dish antennas. Installation requires guy wires or support cables and appropriate mounting hardware (not included).
Main Features
- Extended height: 40 ft (12 m); retracted height: 10 ft (3 m)
- AWG 20 industrial hot-dip galvanized steel tubing
- 4 telescopic sections, 10 ft (3 m) each
- Maximum load capacity: 13.2 lbs (6 kg)
- Maximum antenna diameter: 9.8 in (25 cm)
- Total weight: 24 lbs (11.19 kg)
- Includes assembly screws
- ISO 9000 manufacturing standards
Performance
Extended height: 40 ft (12 m)
Retracted height: 10 ft (3 m)
Number of sections: 4
Section length: 10 ft (3 m) each
Maximum load capacity: 13.2 lbs (6 kg)
Maximum antenna diameter: 9.8 in (25 cm)
Recommended application: Wireless equipment such as Ubiquiti or similar
Physical & Electrical
Tube material: AWG 20 industrial hot-dip galvanized steel
Total weight: 24 lbs (11.19 kg)
Manufacturing standard: ISO 9000
Package Contents
Included: Mast sections 2, 3, 4, and 5
Included: Assembly screws
Technical Notes
- Mast use is limited to the load capacity and area specified for each mast.
- Every mast must be secured with guy wires or at least heavy-gauge galvanized wire.
- Do not climb directly on or lean ladders against this telescopic mast.
- For equipment adjustment, use a step ladder or scaffolding with the mast retracted to its minimum 10 ft (3 m) height corresponding to the first section.
Typical applications: Wireless ISP installations, point-to-point and point-to-multipoint links, temporary communication deployments, and surveillance camera mounting where elevated positioning is required.
