Arm type "F" for STZ-35G Sections, Hot Dip Galvanized
- Brand / Vendor: SYSCOM TOWERS
- Hardware Model / MPN: SBL-35G
- Deal Status: ⚡ Special Deal (20% OFF)
- Condition: 100% Brand New, Factory-Sealed Commercial Gear
- Category: Hardware
- Fulfillment Origin: Dispatches from Texas & Florida distribution hubs
- Binational Availability: Commercial procurement ready for USA and Mexico
Brand: SYSCOM TOWERS | Model / MPN: SBL-35G
Availability: Standard Supplier Lead Time
The SBL-35G is an F-type mounting arm designed for lateral antenna installation on STZ-35G tower sections. Constructed from ASTM A36 structural steel with hot-dip galvanization per NMX-H-004-SCFI-2008, this assembly provides a 1 m x 1 m (3.3 ft x 3.3 ft) compact frame for supporting omnidirectional antennas up to 1.05 m (3.4 ft) in length. The main tube and arm extension use 1-inch Schedule 30 pipe, while lateral arms employ 3/4-inch Schedule 30 pipe for balanced load distribution. The 7.45 kg (16.42 lbs) assembly bolts directly to STZ-35G sections without additional adapters.
Main Features
- ASTM A36 structural steel construction
- Hot-dip galvanized per NMX-H-004-SCFI-2008
- 1 m x 1 m (3.3 ft x 3.3 ft) compact frame
- 1-inch Schedule 30 main tube and extension
- 3/4-inch Schedule 30 lateral arms
- Direct compatibility with STZ-35G tower sections
Physical Specifications
- Overall length: 1 m (3.3 ft)
- Overall height: 1 m (3.3 ft)
- Main tube diameter: 1' Schedule 30
- Arm extension tube diameter: 1' Schedule 30
- Arm extension length: 74.5 cm (29.3 in)
- Lateral arm tube diameter: 3/4' Schedule 30
- Lateral arm length: 25.5 cm (10.0 in)
- Height between lateral arms: 33.9 cm (13.3 in)
- Weight: 7.45 kg (16.42 lbs)
Material & Protection
- Material: ASTM A36 steel
- Protection: Hot-dip galvanized per NMX-H-004-SCFI-2008
Compatibility & Application
- Compatible with STZ-35G tower section
- Intended for lateral antenna mounting (max. 1.05 m / 3.4 ft)
Typical applications: cellular base stations, point-to-multipoint wireless links, and broadcast antenna installations requiring lateral offset from the tower face.
Isometric View:
