Industrial Power Supply 48 VDC 240 W for DIN mount
- Brand / Vendor: MEANWELL
- Hardware Model / MPN: PWR-240-48
- Deal Status: ⚡ Special Deal (17% OFF)
- Condition: 100% Brand New, Factory-Sealed Commercial Gear
- Category: Networking
- Fulfillment Origin: Dispatches from Texas & Florida distribution hubs
- Binational Availability: Commercial procurement ready for USA and Mexico
Ideal 48V DC Power Feeding Solution for PoE Industrial Equipment
The DC single output industrial DIN-rail power supply units provide sufficient 48V power to industrial PoE equipment, such as industrial PoE Ethernet switches and industrial PoE wireless access points. The model name and specification is:
PWR-240-48 (MEAN WELL -- NDR-240-48):
-
- 240W 48V DC Single Output Industrial DIN-rail Power Supply (-20 ~ 70 degrees C)
Output:
• Output Voltage: 48 Vdc
• 5A
• Power: 240 W
• Adjustable voltage: 48 ~ 53 Vdc
Input:
• Input voltage: 85 ~ 264 Vac
• Frequency Range: 47 ~ 63 Hz
• Power Factor: 0.99/115 Vac, 0.96/230 Vac
• Efficiency: 85%
• AC: 2.8A/115 Vac, 1.4A/230 Vac
Protection:
• Automatic turns off and turns on when failure is fixed
• Overcharge: 105 ~ 150%
• Over-voltage: 54 ~ 60V
• Over-temperature
Physcial:
• Operating temperature: 14 to 158 ºF (-10 ~ 70 ºC)
• Dimensions: 4.94 x 4.93 x 3.94' (125.5 x 125.2 x 100 mm)
• Weight: 2.65 lbs (1.2 kg)
Certifications:
UL508, UL60950-1, TUV 60950-1, EN55011, EN55022 (CISPR22) B Class, EN61000-3-2,3, EN61000-4-2-,3,4,5,6,8,11, EN55024, EN61000-6-2 (EN50082-2) High industrial level, Criteria A.
*Cables not included.
