1000 ft Outdoor Cat6 UTP Cable, 24 AWG Bare Copper, Black
- Brand / Vendor: PRECISION
- Hardware Model / MPN: PSCCAT6EXT
- Deal Status: ⚡ Special Deal (20% OFF)
- Condition: 100% Brand New, Factory-Sealed Commercial Gear
- Category: Video Surveillance
- Fulfillment Origin: Dispatches from Texas & Florida distribution hubs
- Binational Availability: Commercial procurement ready for USA and Mexico
| PRECISION • Structured Cabling • Outdoor Series PSC-CAT6-EXT 1000 ft Outdoor Cat6 UTP Cable • 24 AWG Bare Copper • Black Built for the outside plant: 24 AWG bare copper conductors, PoE+ (IEEE 802.3at) support, and an LDPE outdoor jacket rated for -4°F to 140°F — the dependable run between your NVR and every outdoor camera and access point.
|  | |||||
| Real Bare Copper, Real PoE+ 24 AWG bare copper conductors — not CCA — deliver the low DC resistance that long-distance PoE feeding demands. IEEE 802.3at (PoE+) compliant for powering cameras, access points, and radios at the far end of the run. | Made for the Outdoors The black LDPE outdoor sheath shrugs off weather in operating temperatures from -4°F to 140°F (-20°C to 60°C) — the run from the IDF to the parking-lot camera, rooftop AP, or gate intercom, without conduit anxiety. | Certified-Length Performance Fluke Permanent Link tested up to 90 m (295 ft) — the full TIA channel distance — and built to ANSI/TIA-568-D, ISO/IEC 11801 and EN 50173. A rip cord speeds up jacket stripping on every termination. |
The Outdoor Run Your Surveillance Project Depends On
| The PSC-CAT6-EXT is PRECISION's Category 6 UTP cable engineered for outdoor voice, data, security, and video applications — IP megapixel and analog CCTV installations, wireless access points, gigabit outdoor video/data links, and long-distance PoE/PoE+ feeding. Construction follows the classic Cat6 recipe done right: four twisted pairs of 24 AWG bare copper with polyethylene insulation (Ø 0.91 mm) around a pair separator cross, jacketed in black LDPE with an overall diameter of just 0.224 in (5.70 mm) — slim enough for crowded conduit and tight service loops, with standard TIA color coding for fast, error-free terminations. Handling in the field is equally practical: minimum bending radius of 8×D during installation and 4×D installed, an installation temperature window of 32°F to 122°F (0°C to 50°C), and a built-in rip cord so techs strip jacket cleanly without nicking pairs. Every run is backed by Fluke Permanent Link performance up to 90 m, so your certification reports pass the first time — on the 1,000 ft (305 m) spool format integrators expect. | |
Technical Specifications
| General | |
|---|---|
| Part Number | PSC-CAT6-EXT |
| Category / Type | Category 6 UTP, 4 pairs, outdoor |
| Presentation | 1,000 ft (305 m) spool, black |
| Standards | ANSI EIA/TIA-568-D; ISO/IEC 11801 2nd Edition; EN 50173; IEEE 802.3at (PoE+) |
| Applications | Voice, data, security and video; IP megapixel and analog CCTV installations; wired access points; gigabit outdoor video/data installations; long-distance PoE feeding, PoE+ |
| Construction | |
|---|---|
| Conductor | Bare copper wire, 24 AWG |
| Insulation | Polyethylene, Ø 0.036 in (0.91 ± 0.02 mm) |
| Insulation Colors | Blue/White-Blue, Orange/White-Orange, Green/White-Green, Brown/White-Brown (standard TIA color code) |
| Twisting / Lay-Up | 2 cores to the pair; 4 pairs to the core (with pair separator cross) |
| Rip Cord | Yes |
| Sheath | LDPE, black (outdoor) |
| Overall Diameter | 0.224 in (5.70 ± 0.2 mm) |
| Mechanical Properties | |
|---|---|
| Minimum Bending Radius (Installation) | 8 × D |
| Minimum Bending Radius (Installed) | 4 × D |
| Temperature Range (Operation) | -4°F to 140°F (-20°C to +60°C) |
| Temperature Range (Installation) | 32°F to 122°F (0°C to +50°C) |
| Fluke Permanent Link | Up to 295 ft (90 m) |
| Ideal Applications Outdoor IP megapixel and analog CCTV camera runs • PoE/PoE+ feeding of cameras, access points, and radios at distance • Gigabit outdoor video and data links between buildings • Parking lots, perimeters, gates, and rooftop wireless installations • Campus and industrial-yard structured cabling extensions • Certification-grade projects requiring Fluke-tested permanent links |
