UHF Male Crimp Connector, Non-Solder Pin
- Brand / Vendor: Times Microwave
- Hardware Model / MPN: EZ-400-UM-X
- Deal Status: ⚡ Special Deal (20% OFF)
- Condition: 100% Brand New, Factory-Sealed Commercial Gear
- Category: Networking & Telecom Infrastructure
- Fulfillment Origin: Dispatches from Texas & Florida distribution hubs
- Binational Availability: Commercial procurement ready for USA and Mexico
The EZ-400-UM-X is a UHF male crimp connector from Times Microwave's EZ series, designed for simplified field installation on low-loss coaxial cables. It features a captive non-solder pin that eliminates the need for soldering during assembly, reducing installation time and potential connection failures. The connector utilizes a foldable (pleated) ferrule design that ensures secure mechanical attachment to the cable braid. Gold-plated center contact and copper ferrule construction provide stable electrical performance across the operating frequency range.
Main Features
- UHF male connector with captive non-solder center pin
- Compatible with RG-8, Belden 9913, Times LMR400, CNT400, and RG8USYS cables
- Foldable ferrule design for rapid, secure crimp termination
- Gold-plated center contact for corrosion resistance
- Copper (Cu) ferrule material
- 50 Ohms impedance
- Frequency range: DC to 3 GHz
- Vibration and extreme shock resistant construction
Electrical & Performance
- Impedance: 50 Ohms
- Frequency range: DC ~ 3 GHz
- Center contact: Gold plated
Physical & Mechanical
- Connector type: UHF Male
- Assembly mode: Foldable (pleated ferrule)
- Ferrule material: Copper (Cu)
- Vibration and extreme shock resistant
Cable Compatibility
- RG-8
- Belden 9913
- Times LMR400
- CNT400
- RG8USYS
Typical applications: RF communications infrastructure, amateur radio installations, wireless base station cabling, and low-loss coaxial systems requiring reliable field-terminated connections.
