Relay with Contact NO, NC
- Brand / Vendor: ACCESSPRO
- Hardware Model / MPN: PRORELAY
- Deal Status: ⚡ Special Deal (20% OFF)
- Condition: 100% Brand New, Factory-Sealed Commercial Gear
- Category: Access Control
- Fulfillment Origin: Dispatches from Texas & Florida distribution hubs
- Binational Availability: Commercial procurement ready for USA and Mexico
Brand: ACCESSPRO | Model / MPN: PRORELAY
Availability: Standard Supplier Lead Time
The PRORELAY is a compact relay module designed for integration into access control systems, alarm panels, and general automation applications. It operates on 12 Vdc power and provides SPDT output contacts (NO, NC, COM) capable of switching loads up to 3 A at 125 VAC. A red LED provides clear visual indication of relay activation status, facilitating troubleshooting and status verification during installation and maintenance. The module is rated for an extended operating temperature range of -20 to 70 degrees C, making it suitable for indoor and protected outdoor environments. Its small form factor of 39x24x20 mm allows flexible mounting in confined spaces such as junction boxes, controller enclosures, and door frames.
Main Features
- 12 Vdc power input for standard security system compatibility
- SPDT relay output with NO, NC, and COM terminals
- 3 A / 125 VAC switching capacity for common loads
- Red LED indicator for relay activation status
- Operating temperature: -20 to 70 degrees C
- Compact dimensions: 39x24x20 mm
- Weight: 18 g
Specifications
Electrical
- Power: 12 Vdc
- Output: NO, NC and COM
- Supports up to 3 A / 125 VAC
Physical & Environmental
- Operating temperature: -20 to 70 degrees C
- Weight: 18 g
- Dimensions: 39x24x20 mm
Typical applications include door strike and magnetic lock control in access control systems, alarm output expansion for panel notifications, and general-purpose automation switching where isolated relay contacts are required.
