¿What is HD-TVI 1080P Lite?

Allows 720P DVRs to add 1080P (2 Megapixel) HD-TVI TurboHD and HD-CVI cameras (other manufacturers) with 960 x 1080 resolution. Remember that Full HD is 1920 x 1080 and that is why the DVR will not be able to record in Full HD. With this advantage, we can use motorized lens TURBOHD cameras to move the lens remotely.

Features:

• TURBOHD technology 1080P Lite Ver. 3.0

• Supports 5 technologies: TVI / CVI / AHD / Analog / IP

• Supports 4 channels TURBOHD / analog + 1 channel IP = 5 channels in total.

• 1 Audio Input / 1 Audio Output (RCA connector).

• Supports H.265+ / H.265 / H.264+ / H.264 compression.

• Compatibility with Internet Explorer / Chrome (ietab).

• Capacity for 1 SATA 4 TB HDD.

• Simultaneous HDMI / VGA Full HD 1080p video output.

• Supports Hikvision DDNS Service.

• Supports Hik-Connect P2P.

• Compatible with iVMS-4200 client software (Windows, iOS), Hik-Connect (Android, iPhone, iPad, iPod Touch).

Video Channels:

• HD-TVI: 1080p Lite / 720p@ 12 IPS.

• CVBS: WD1@ 30 IPS.

• AHD: 1080p Lite / 720p@ 12 IPS.

• CVI: 1080p Lite / 720p@ 12 IPS.

• IP: 2 Megapixel

• BNC Connector.

Video Coding:

• Main stream: 1080P Lite / 720p / WD1 / VGA / 4CIF.

• Sub stream: CIF / QCIF

• Bitrate: 32 Kbps up to 6 Mbps.

Video Output:

• Simultaneous HDMI and VGA video output.

• Supported Resolutions: 1920 x 1080 / 1280 x 1024 / 1280 x 720 / 1024 x 768.

Recording:

• Recording with automatic overwriting.

• Configurable to start recording with a single click.

• Recording scheduled via calendar, manual, or event.

Search and Playback:

• Instant playback of a camera in live Multi-View mode.

• Simultaneous synchronous 4-channel playback at 1080p Lite in forward/backward.

• Local and remote playback, with log or event search.

• Recording identification through tags and playback through tags.

• Important segment blocking to avoid overwriting.

Events:

• Audible alert, Pop-Up, e-mail notification, and notification to the monitoring center when an event is triggered.

• Motion detection alarm, camera blocking, and disconnection, configurable by channel.

• Monitor HDD status, network, inputs, and camera status with remote notifications.

Network:

• 6 simultaneous users.

• Supports Main and Sub Stream.

• Supported Protocols: TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP, HTTP, HTTPS.

Interface:

• 1 Network Port: RJ-45 10/100 Mbps.

• 2 USB 2.0 Ports (Supports mouse, included).

Physical and Electrical Characteristics:

• Power Supply: 12 VDC (Included)

• Consumption: Max. 8 W.

• Operating Temperature: 14 ~ 131°F (-10 ~ 55 ºC).

• Dimensions: 7.87 x 7.87 x 1.77" (200 x 200 x 45 mm).

• Weight: 1.76 lb (800 g).

• 5-year warranty.
